AMT 4500 Hydraulic Hoist Lift – 4.5 Ton 2 Post Car Lift with RAM Cylinders, Adjustable Top Bar, Door Protection & Automatic Arm Locking | Heavy-Duty Garage Lift for SUVs & Sedans

The AMT 4500 Hydraulic Hoist Lift is engineered to deliver superior lifting performance while withstanding the rigors of daily workshop operations. With a lifting capacity ranging from 4,500 to 6,500 kg (depending on model), this 2-post lift combines strength, precision, and advanced safety systems—making it a reliable choice for sedans, SUVs, vans, and light commercial vehicles.

At its core, the AMT 4500 is powered by RAM-type hydraulic cylinders for smooth, consistent lifting. These cylinders are supported by a maximum operating hydraulic pressure of 180 / 200 / 270 bar, ensuring stable operation under heavy loads.

To guarantee balance between posts, the lift integrates a pre-stretched wire rope synchronization system. This system eliminates uneven lifting, providing maximum safety and accuracy at all times.

The adjustable screw pads adapt to different underbody configurations, giving technicians precise control over contact points. This versatility is essential for servicing modern vehicles of varying chassis designs.

Safety is built-in with an automatic arm locking mechanism that engages during every lift. When lowering, the manual hand lever release provides controlled and effortless disengagement, ensuring technician confidence.

• Door Rubber Blocks: Prevent accidental scratches and dents.

• Top Limit Touch Bar: Automatically stops lifting at 2,062 mm maximum height, preventing damage to vehicle roofs.

• Adjustable Top Cross Bar: Offers up to 250 mm adjustment for ceiling height flexibility.

• High-Grade Steel Structure with anti-friction carriage guides for smoother operation.

• Powder-coated finish for corrosion resistance.

• Motor Options:

  • 3-Phase Motor: 230V / 400V, 50/60Hz, 3/4 KW.

  • Single-Phase Motor: 220V, 50–60Hz, 3/4 KW.

• Noise Levels: 68.2 dB(A) average – workshop friendly.

• Distance Between Columns: 3,285 / 3,150 mm.

• Overall Height Options: 4,050 / 4,650 / 5,250 mm.

• Minimum Height: 115 mm for low-clearance vehicles.

• Fixing System: Optional Fisher FBN II 16×100 anchors + washers for secure floor mounting.

• Hydraulic Oil: ISO VG32 Tipo, 9 L optional capacity.

• Total Lift Weight: 974 / 988 / 1,072 kg (depending on configuration).

✅ 4.5–6.5 Ton Capacity – From compact cars to heavy SUVs and vans
✅ Auto Arm Locks + Manual Release – Maximum operator safety
✅ Top Limit Bar + Rubber Protection – Vehicle protection built-in
✅ Fast Cycle Time – 50 seconds up / 50 seconds down under load
✅ Workshop-Grade Durability – Anti-friction carriage guides + powder coating
✅ Flexible Power Options – Single or three-phase motor support
✅ Certified Reliability – Built to perform in professional garages
